Model Variations |
CG3100X-BK |
Panel: |
|
Type |
IPS |
Backlight |
Wide-Gamut LED |
Size |
30.5" (77.5 cm) |
Native Resolution |
4096 x 2160 (17:9 aspect ratio) |
Viewable Image Size (H x V) |
685.7 x 361.6 mm |
Pixel Pitch (H x V) |
0.167 x 0.167 mm |
Pixel Density |
152 ppi |
Display Colors |
1.07 billion colors, 10-bit display (24-bit LUT) |
Viewing Angles (H / V, typical) |
178°, 178° |
Brightness (typical) |
500 cd/m2 |
Contrast Ratio (typical) |
1800:1 |
Response Time (typical) |
15 ms (gray-to-gray) |
Color Gamut (typical) |
Adobe RGB: 97%, DCI-P3: 99% |
Video Signals: |
|
Input Terminals |
USB Type-C (DisplayPort Alt Mode, HDCP 2.3), DisplayPort (HDCP 2.3), HDMI (Deep Color, HDCP 2.3) |
Digital Scanning Frequency (H / V) |
USB Type-C, DisplayPort: 25 - 137 kHz / 23 - 61 Hz
HDMI: 15 - 136 kHz / 23 - 61 Hz |
USB: |
|
Upstream |
USB 5Gbps: Type-C (DisplayPort Alt Mode, Power Delivery Source 94 W max.), USB 5Gbps: Type-B |
Downstream |
USB 5Gbps: Type-A x 2
USB 2.0: Type-A x 2 |
USB LAN Adapter |
RJ-45 (1000BASE-T) |
Audio: |
|
Input Terminals |
USB Type-C, DisplayPort, HDMI |
Output Terminals |
Headphones (Stereo mini jack) |
Power: |
|
Power Input |
AC 100 - 240 V, 50 / 60 Hz |
Typical Power Consumption |
86 W |
Maximum Power Consumption |
270 W |
Power Save Mode |
0.5 W or less |
Built-in Calibration Sensor |
Yes |
Features & Functions: |
|
Brightness Stabilization |
Yes |
Digital Uniformity Equalizer |
Yes |
Preset Modes |
User, BT.2020, BT.709, DCI-P3, PQ_DCI-P3, HLG_BT.2100, Adobe RGB, sRGB, Calibration (CAL), SYNC_SIGNAL |
HDR Gamma |
HLG, PQ curve |
OSD Languages |
English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese |
Others |
Color Adjustment, PQ Option, HLG Option, SelfCalibration, Input Color Format, YUV Color Matrix, Input Range, I/P Conversion, Picture Expansion, Nearest Neighbor, Zoom, BT.709 Gamut warning, Luminance Warning, Marker, Menu Rotation, Power Save, Input Skip, Mode Skip, Custom Key, Information Display, Key Lock, DUE Priority, Ethernet, Pixel Inspection |
Physical Specifications: |
|
Dimensions (Landscape, W x H x D) |
721 x 428.1 - 583.1 x 290 mm |
Dimensions (Without Stand, W x H x D) |
721 x 413.9 x 87.2 mm |
Dimensions (Landscape with Hood, W x H x D) |
731 x 433.1 - 588.1 x 389.3 mm |
Net Weight |
12.3 kg |
Net Weight (Without Stand) |
8.9 kg |
Net Weight (With Hood) |
13.1 kg |
Height Adjustment Range |
155 mm |
Tilt |
35° Up, 5° Down |
Swivel |
344° |
Hole Spacing (VESA Standard) |
100 x 100 mm |
Environmental Requirements: |
|
Operating Temperature |
Landscape: 0 - 35°C
Portrait: 0 - 30°C |
Operating Humidity (R.H., non condensing) |
20 - 80% |
Certifications & Standards (Please contact EIZO for the latest information.) |
CB, CE, UKCA, TUV/GS, cTUVus, FCC-B, CAN ICES (B), VCCI-B, RCM, RoHS, WEEE, TUV/Ergonomics, FograCert Softproofing System (class A) |
Proprietary Software: |
|
Color Management Software ColorNavigator 7 |
Supported |
Supplied Accessories (May vary by country. Please contact EIZO for details.) |
|
Signal Cables |
USB Type-C (2 m), HDMI (2 m) |
Others |
AC power cord, USB Type-A - USB Type-B cable (2 m), Setup guide, Factory Report, Monitor hood, Warranty card |
Warranty |
5 Years |
